| Part Number | Download | Circuit | Status | Polarity |
PCM(W) |
IC(A) |
VCBO(V) |
VCEO(V) |
VEBO(V) |
hFEMin |
hFEMax |
hFE@VCE(V) |
hFE@IC(A) |
VCE(sat)(V) |
VCE(sat)@IC(A) |
VCE(sat)@IB(A) |
Package |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
2SB647A |
 |
 |
Active |
PNP |
0.75 |
-1 |
-120 |
-100 |
-5 |
60 |
320 |
-5 |
-0.15 |
-1 |
-0.5 |
-0.05 |
TO-92L |
|
MMSTA06 |
|
 |
Active |
NPN |
0.2 |
0.5 |
80 |
80 |
4 |
100 |
400 |
1 |
0.01 |
0.25 |
0.1 |
0.01 |
SOT-323 |
| BA847 |
|
 |
Active |
NPN |
0.275 |
0.1 |
50 |
45 |
6 |
220 |
475 |
5 |
0.002 |
0.5 |
0.1 |
0.005 |
DFN1006-3L |
|
CJZ606PL |
|
 |
Active |
PNP |
2 |
-6 |
-100 |
-60 |
-7 |
100 |
300 |
-1 |
-2 |
-0.5 |
-5 |
-0.5 |
SOT-223 |
|
CJZ606NL |
|
 |
Active |
NPN |
2 |
6 |
150 |
60 |
7 |
100 |
400 |
1 |
2 |
0.35 |
6 |
0.3 |
SOT-223 |
|
2SD669A |
|
 |
Active |
NPN |
1.5 |
1.5 |
180 |
160 |
5 |
160 |
320 |
5 |
0.15 |
1 |
0.5 |
0.05 |
SOT-89-3L |
|
MJD45H11 |
|
 |
Active |
PNP |
1.8 |
-8 |
-80 |
-60 |
-6 |
80 |
600 |
-5 |
-1 |
-0.8 |
-8 |
-0.4 |
TO-252-2L |
|
MJD44H11 |
|
 |
Active |
NPN |
1.8 |
8 |
80 |
60 |
6 |
80 |
600 |
5 |
1 |
0.8 |
8 |
0.4 |
TO-252-2L |
|
CJA606NL |
|
|
Active |
NPN |
1.5 |
6 |
150 |
60 |
7 |
100 |
400 |
1 |
2 |
0.28 |
6 |
0.3 |
SOT-89-3L |
|
CJA606PL |
|
|
Active |
PNP |
1.5 |
-6 |
-100 |
-60 |
-7 |
100 |
300 |
-1 |
-2 |
-0.28 |
-5 |
-0.5 |
SOT-89-3L |
|
2SA1013 |
|
|
Active |
PNP |
0.9 |
-1 |
-160 |
-160 |
-6 |
60 |
320 |
-5 |
-0.2 |
-1.5 |
-0.5 |
-0.05 |
TO-92MOD |
|
2SA1020 |
|
|
Active |
PNP |
0.9 |
-2 |
-50 |
-50 |
-5 |
70 |
240 |
-2 |
-0.5 |
-0.5 |
-1 |
-0.05 |
TO-92MOD |
|
2SA1832 |
|
 |
Active |
PNP |
0.1 |
-0.15 |
-50 |
-50 |
-5 |
120 |
400 |
-6 |
-0.002 |
-0.3 |
-0.1 |
-0.01 |
SOT-523 |
|
TP847LED03 |
|
 |
Active |
NPN |
0.1 |
0.1 |
50 |
45 |
6 |
220 |
475 |
5 |
0.002 |
0.4 |
0.1 |
0.005 |
WBFBP-03E |
|
TP857LED03 |
|
|
Active |
PNP |
0.1 |
-0.1 |
-50 |
-45 |
-6 |
220 |
475 |
-5 |
-0.002 |
-0.4 |
-0.1 |
-0.005 |
WBFBP-03E |
|
2SC2383 |
|
|
Active |
NPN |
0.9 |
1 |
160 |
160 |
6 |
60 |
320 |
5 |
0.2 |
1 |
0.5 |
0.05 |
TO-92L |
|
TK3904LED03 |
|
|
Active |
NPN |
0.1 |
0.2 |
60 |
40 |
6 |
100 |
300 |
1 |
0.01 |
0.3 |
0.05 |
0.005 |
WBFBP-03E |
|
TK3906LED03 |
|
|
Active |
PNP |
0.1 |
-0.2 |
-40 |
-40 |
-5 |
100 |
300 |
-1 |
-0.01 |
-0.4 |
-0.05 |
-0.005 |
WBFBP-03E |
|
2SC1623 |
|
|
Active |
NPN |
0.2 |
0.1 |
60 |
50 |
5 |
90 |
600 |
6 |
0.001 |
0.3 |
0.1 |
0.01 |
SOT-23 |
|
2SA554 |
|
 |
Active |
PNP |
0.5 |
-2 |
-100 |
-100 |
-6 |
120 |
270 |
-3 |
-0.1 |
-0.2 |
-0.5 |
-0.025 |
SOT-89-3L |
